Pt100 class F0.15 up to 600°C with optimized ESD design
Pt 100 Ohm RTD, -200°C to +600°C
Platinum temperature sensor with ESD optimized design, 2.2 x 2 x 1.1 mm,10mm long NiPt wire
Product Name
P0K1.232.6W.A.010
Nominal resistance
100 Ω at 0 °C
Operating temperature range
-200 °C to +600 °C
TCR
Pt 3850 ppm/K
Tolerance/class
IEC 60751 F0.15 (IST AG reference class A)
Connection type
Pt/Ni-wire, Ø 0.2 mm
Wire length
10 mm
Special
ESD optimized design (IEC/EN 61000-4-2)
