PT100 class F0.1 up to 200°C with insulated stranded wires (2x red & 2x white)
-50°C up to 200°C, 2.5 x 1.6 x 1.1 mm, 4-wire extension, 300 mm insulated stranded wire
in stock (fast delivery), colour coding according to IEC standard, stranded wires suitable for connector mounting, slim design suitable for small installation spaces, 4-wire extension
Product Name
P0K1.216.2K.Y.300-4
Nominal resistance
100 Ω at 0 °C
Operating temperature range
-50 °C to +200 °C
TCR
Pt 3850 ppm/K
Chip size/dimensions
2.5 x 1.6 x 1.1 mm
Tolerance/class
IEC 60751 F0.1 (IST tolerance class Y)
Connection type
Cu/Ag stranded wire, PTFE-insulated, 4x Cu/Ag stranded wire AWG 28/7, PTFE-insulated (2x red, 2x white)
Wire length
300 mm
Packaging
Loose in bags
154584
1554584
